Chapter 2. Setting Up 9500 MXC CT
Vol. IV-2-6 Alcatel-Lucent
Setting Up Your PC TCP/IP Properties
Introduction
Your CT PC must have a LAN-compatible address installed. Each
Node/Terminal in a 9500 MXC network has a unique network address, unless
connected on a LAN at the same site, so you must change your PC TCP/IP
settings each time you physically connect to a different Node/Terminal.
This requires configuration of your PC LAN card TCP/IP settings, so your PC is
recognized as a device on the 9500 MXC NMS LAN.
Procedures are provided for Windows 2000 and XP.
Procedure: Windows 2000
This procedure is based on a PC running Windows 2000 PC, there may be small
differences with other versions of Windows.
For guidance during this procedure refer to Example - Changing TCP/IP
Properties on page 2-8.
1. Click on the LAN (network connection) icon in the System Tray, located in
the lower right corner of your PC screen.
Or, from the Control Panel of your PC, select
Network and Dial-up
Connections > Local Area Connection.
The Local Area Connection Status window is displayed.
2. Click
Properties.
3. Select
Internet Protocol (TCP/IP).
4. Ensure its associated box is ticked.
LAN Icon
