3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-3-1
Chapter 3. Installation and
Configuration Process
9500 MXC CT provides the tools needed to install and commission a link
between:
• 9500 MXC Nodes
• a 9500 MXC Node and a 9500 MXC Terminal
• 9500 MXC Terminals
References to Node and Terminal in this manual have the following meanings:
•
9500 MXC Node refers to the INU or INUe with the ODU 300ep and/or
ODU 300hp.
•
9500 MXC Terminal refers to the IDU with the ODU 300ep or ODU 300hp.
The main topics are:
• Essential Information on page 3-2
• 9500 MXC CT Menus on page 3-4
• Procedure Overview for a New Installation on page 3-7
• Configuration Changes to An Existing Installation on page 3-11
From new each end of the link must be locally configured. Once a link has been
established, both ends can be re-configured from one end providing the
re-configuration does not dis-establish the link connection.
