About This Manual
Welcome to 9500 MXC
The 9500 MXC Microwave Radio System comprises Node and the Terminal
variants. Both are split-architecture radios with an antenna-mounted outdoor unit
and a rack-mounted indoor unit.
The 9500 MXC Node supports multiple point-to-point radios for PDH, SDH,
and/or Ethernet, on a single product platform, to form a complete network node
for star or ring configurations on frequency bands from 6 to 38 GHz.
The 9500 MXC Terminal is optimized for single-link installations or where
back-to-back network connection of terminals is preferred. Terminals may also
be used to spur from a 9500 MXC Node. Different versions are available for
PDH, SDH or Ethernet, on frequency bands 5 to 38 GHz.
Purpose
This manual provides information on installing, commissioning and
troubleshooting a 9500 MXC microwave radio system. Technical descriptions
are at a module and system level.
Intended Audience
The information in this manual is for use by trained technicians or engineers. It
does not provide information or instruction on basic technical procedures.
Alcatel-Lucent recommends you read the relevant sections of this manual
thoroughly before beginning any installation or operational procedures on the
9500 MXC.
