3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-7-1
Chapter 7. Node and Terminal
Plug-ins
The plug-ins screen is used for Node and Terminal configuration. Table 7-1 lists
module references used within the screens.
Table 7-1. Module References for Node and Terminal
Refer to:
• Plug-Ins Screens on page 7-2
• Link Configuration on page 7-3
• DAC/Tributary Configuration on page 7-25
• AUX Configuration on page 7-84
Function Node/Terminal Module References
Radio LINK or RING. A LINK comprises one RAC/IDU for
a non-protected link, two for a protected link.
A RING comprises east and west pairings of RAC/
RAC, RAC/DAC 155oM, or DAC 155oM / DAC
155oM.
Tributary DATA for PDH and SDH tributaries. DATA comprises
one DAC/IDU for a non-protected trib configuration,
two for protected.
DAC for Ethernet DACs and the IDU ES Ethernet port
module.
Auxiliary AUX
