9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. V-2-33
Using CT Diagnostics Screens
CT Diagnostics screens provide tools for locating and diagnosing 9500 MXC
problems. Table 2-4 provides a summary of essential functions.
Getting the best from these screens requires familiarity. Time spent on their
layout, features, options and applications, will be time well spent.
With exception of diagnostic options provided in the System Controls screen,
such as locks and loopbacks, all screens can be fully exercised without impacting
traffic.
Table 2-4. Diagnostic Screen Function Summary
Click on screen type in the Screen column to open a full description.
Screen Function Tips
System Summary System Summary is the opening CT screen.
Provides a high-level summary, by module,
of all detected problems, using alarm severity
and problem icons.
Includes a system layout function for an INU/
INUe.
• Mouse-over for tooltips.
• Left click a module to go straight its
alarm screen. Right click to view a menu
of quick-access screen options.
• Left click the circuits area to go to the
circuits screen. Right click to select
between the circuits and circuit loopback
screens.
