Chapter 1. 9500 MXC System Overview
Vol. II-1-12 Alcatel-Lucent
• VLAN tagging.
• Throughputs to 300 Mbps per transport channel.
• Assignment to radio or fiber links.
• Assignment of total link capacity to Ethernet, or split between Ethernet and E1/
DS1 traffic.
• Compatibility with DAC ES.
Figure 1-21. DAC GE
AUX
AUX provides synchronous and asynchronous auxiliary data channels, NMS
porting, and alarm input and output functions. Data options are sync at 64 kbps or
async up to 19.2 kbps.
Figure 1-22.
NPC
NPC provides redundancy for the NCC TDM bus management and power supply
functions.
Figure 1-23. NPC
For more information on the 9500 MXC Node, refer to Chapter 3.
