Chapter 2. 9500 MXC Terminals
Vol. II-2-14 Alcatel-Lucent
Table 2-7. IDU ES / RAC Compatibility: ETSI
Table 2-8. IDU ES / RAC Compatibility: ANSI
Ethernet
Assignment
BW MHz Modulation IDU ES RAC30v3 RAC3X
10 Mbps 7 MHz QPSK X X N/A
20 Mbps 7 MHz 16QAM X X N/A
20 Mbps 14 MHz QPSK X X N/A
32 Mbps 7 MHz 64QAM X X N/A
40 Mbps 28 MHz QPSK X X N/A
40 Mbps 14 MHz 16QAM X X N/A
80 Mbps 28 MHz 16QAM X X N/A
106 Mbps 28 MHz 32QAM X X N/A
150 Mbps 56 MHz 16QAM X N/A X
150 Mbps 28 MHz 128QAM X X N/A
190 Mbps 28 MHz 256QAM X N/A X
196 Mbps 56 MHz 64QAM X N/A X
Ethernet
Assignment
BW Modulation IDU ES RAC30v3 RAC3X
43 Mbps 10 MHz 64 QAM X X N/A
49 Mbps 20 MHz 16 QAM X X N/A
49 Mbps 40 MHz QPSK X N/A X
108 Mbps 30 MHz 16 QAM X X N/A
108 Mbps 40 MHz 32 QAM X N/A X
154 Mbps 30 MHz 128 QAM X X N/A
154 Mbps 40 MHz 32 QAM X N/A X
154 Mbps 50 MHz 16 QAM X N/A X
