9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-4-3
• Where two ODUs are to be connected to a single antenna for hot-standby or
frequency diversity configurations, a direct-mounting coupler is used. They are
available for equal or unequal loss operation. Equal loss is nominally 3.5/3.5
dB. Unequal is nominally 1.5/6.5 dB.
Further Information
Refer to Volume III, Chapter 2. for information on:
• Installation
• Lightning surge suppression
• Waveguide flange data
Refer to the 9500 MXC datasheets (ETSI or ANSI) for complete specifications.
Bandwidths
Supported
3.5 to 56 MHz 7 to 56 MHz
Tx Power Extended power (except
11 GHz), with a
maximum 30 dB power
control range
High power, with a
maximum 20 dB power
control range
Tuning Range Typically (depending on T/R spacing) 56 MHz at 6 / 7
GHz to 230 MHz at 15 GHz. 340 to 380 MHz on higher
bands.
IF Interface RAC 30, RAC 3X, RAC
40, IDUs
RAC 30, RAC 3X, RAC
40, IDUs
Item ODU 300ep ODU 300hp
