plug-in or chassis change.
The Diagnostics menu provides access to:
• A system status summary, with system layout controls for an INU/INUe.
• System controls for protection locking, loopbacks, Tx muting, BER generation
and measurement.
• Event browser and history screens.
• Alarms status screen.
• Backplane circuit loopbacks (9500 MXC Node only).
• Part-number screen.
The Help Menu provides access to:
• Contact details for Alcatel-Lucent help desks.
• Version data for 9500 MXC CT.
Refresh and Send
• Refresh sends a read request to the radio to provide a configuration update to
the current saved configuration. In situations where a configuration
amendment has caused an unwanted change, clicking Refresh provides a
rollback to the saved configuration.
• Send sends a new configuration to the radio, to be written into the
CompactFlash card. When no changes requiring a Send command have been
made, the flashcard icon within the Send button will be uncolored. When a
change has been made which requires a Send command, to confirm the change
the flashcard icon will first flash yellow three times and then stay yellow until
clicked. When clicked, a Send window with a cancel option is displayed and
will remain open until the send process has been completed.
Figure 3-1 shows the menu-bar menus for a 9500 MXC Node.
Except for the IDU ES, the configuration menu for a Terminal does not display a
Circuits option.
