9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. I-1-7
RF Exposure Guidelines
The following MPE (maximum permissible exposure) calculations have been
produced in accordance with the guidelines of EN 50383/EN 50385. These
calculations represent examples only and do not include every possible
combination of output power and antenna gain.
Occupational is defined as: “The occupationally exposed population consists of
adults who are generally exposed under known conditions and are trained to be
aware of potential risk and to take appropriate precautions”.
Table 1-1. MPE Guidelines
5GHz (4.4 – 5.0GHz)
Transmit Power (dBm) Antenna Gain (dBi) Compliance Boundary
General Public (m)
Compliance Boundary
Occupational (m)
30.5 39.3 8.77 3.91
30.5 32.6 4.06 1.81
0.5 39.3 0.28 0.12
0.5 32.6 0.13 0.06
L6/U6GHz (5.925 – 7.11GHz)
Transmit Power (dBm) Antenna Gain (dBi) Compliance Boundary
General Public (m)
Compliance Boundary
Occupational (m)
30.5 41.5 11.30 5.03
30.5 31.2 3.45 1.54
0.5 41.5 0.36 0.16
0.5 31.2 0.11 0.05
7/8GHz (7.125 – 8.5GHz)
Transmit Power (dBm) Antenna Gain (dBi) Compliance Boundary
General Public (m)
Compliance Boundary
Occupational (m)
30.5 42.9 13.28 5.91
30.5 30.4 3.15 1.40
5.0 42.9 0.71 0.31
5.0 30.4 0.17 0.07
10GHz (10.0 – 10.68GHz)
Transmit Power (dBm) Antenna Gain (dBi) Compliance Boundary
General Public (m)
Compliance Boundary
Occupational (m)
26.0 34.3 2.94 1.31
26.0 33.7 2.74 1.22
-4.0 34.3 0.09 0.04
-4.0 33.7 0.09 0.04
11GHz (10.7 – 11.7GHz)
Transmit Power (dBm) Antenna Gain (dBi) Compliance Boundary
General Public (m)
Compliance Boundary
Occupational (m)
25.0 46.2 10.31 4.59
25.0 27.7 1.23 0.55
2.5 46.2 0.77 0.34
2.5 27.7 0.09 0.04
13GHz (12.75 – 13.25GHz)
Transmit Power (dBm) Antenna Gain (dBi) Compliance Boundary
General Public (m)
Compliance Boundary
Occupational (m)
28.0 47.3 16.53 7.36
28.0 29.6 2.15 0.96
0.0 47.3 0.66 0.29
0.0 29.6 0.09 0.04
