9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-1-7
Figure 1-6. INU
INUe
The INUe requires one NCC and two FANs, and has provision for up to ten
option cards. It supports a maximum of six ODUs for six non-protected links, or
up to three protected/diversity links.
Figure 1-7. INUe
During July 2007 a new IDCe (INUe chassis) will be introduced to replace the
current IDCe. This IDCe accepts a new 2RU FAN and also the current 1RU
FANs.
One 2RU FAN will be supplied as standard with the new IDCe.
