9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-15-5
Tooltips
Mouse-over for tooltips:
• Mouse over an alarm icon for a description of the alarm.
• Mouse-over a circuit line to see its configured capacity, its interconnections,
and current alarm severity as determined by the highest current severity on
modules at each end of the circuit. (Node only).
• Mouse-over a color to see its severity level.
• Mouse-over a module to view its location in the INU/INUe Replaceable Units
graphic (Node only).
Replaceable Units Panel
Replaceable Units shows the physical layout for a 9500 MXC Node.
• Allows easy identification of plug-in types and location. Unconfigured slots are
shown as blanks.
• Colors reflect the alarm severities shown the System Functions panel.
• Mouse-over a slot to highlight its position in the System Function panel.
Status Bar Icons
The Status bar at the bottom of the screen (all CT screens) presents a summary of
Node / Terminal status.
• The alarm severity icon presents the highest severity alarm found.
• The problem icons show all problem types present.
• Right-click on an icon to display a menu of screens relevant to the problem.
• When not in the System Summary screen, left-click on a problem or alarm
severity icon to go directly to the System Summary screen.
Module Naming
For modules a name can be entered or a name changed by right-clicking in a
module, selecting Rename, and typing. The default name is ‘unnamed’.
The name entered will appear in all CT screens where modules are identified by
name. Includes Plug-ins, Protection, Circuits, Networking, System Summary,
System/Controls, History.
