Chapter 15. Diagnostics
Vol. IV-15-50 Alcatel-Lucent
Safety Timer Operation
Figure 15-17 illustrates the operation of the safety timer function. To start a
selection or to manually terminate a selection, the Send button must be clicked to
enable the selection.
The operation illustrated assumes that:
• The default safety timer option has not previously been enabled for the current
CT session (see below).
• The safety timer operation has not been enabled to default to the last setting
used in the Edit > Preferences menu. This selection applies to all CT sessions.
See 9500 MXC CT Menus on page 3-4, Volume IV, Chapter 3.
The safety timer steps, related to Figure 15-17, are:
.
Item Description
1 Click On.
2 Select a timer option and click Ok.
If you click
“Do not ask me this again (use this setting as default)”, the
last safety timer selection will apply for all subsequent System/Controls
‘On’ actions for the current CT session, and the Safety Timer option box
will not appear unless the timer clock is clicked. If you click on the
“Advanced” button, you can enable an “always on” option.
To return to the Safety Timer option box, click a new ‘On’ action, then
click the timer indication to the right side of the Off button.
3 Confirm the selection and click Send to start. The real-time counter displays the
countdown.
4 To terminate before expiry of countdown or to terminate an “always on”
selection, click Off, then Send.
5 When the countdown expires, the default On connection is restored.
