9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. IV-15-53
Figure 15-18. Ring System/Controls Screen
Item Description
1 Tabs to Tx mute and Loopback locks.
2 Protection Controls window. Graphic depicts the operational status for the
node. This example shows normal [unwrapped] operation.
3 Countdown timer indicates the time to go before an unwrap can occur. (No
countdown is indicated in this exampl)e.
4 Tx and Rx locks are supported by a safety timer.
1
2
3
4
