9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-2-23
IDU IDU Status LED provides indications of:
Off IDU power off
Green Normal operation
Orange flashing Configuration not supported, software/ hardware
incompatible, or diagnostic mode selected.
Red Critical alarm (traffic affecting)
9 NMS 10/100Base-T RJ-45 connector provides a port for Ethernet network management access.
Unless DHCP has been configured, Ethernet CT login requires entry of a LAN
compatible IP address on your PC.
Port may also be used to provide NMS connectivity to other co-located
Alcatel-Lucent or third party radios.
The green connection-status LED is on for a valid Ethernet connection. Off
indicates no connection or an invalid connection.
The orange activity LED flashes to indicate Ethernet traffic on the port. The
LED does not flash (is solid on) when there is no traffic activity. (Activity LED
is off when the connection status LED is off).
14 Ethernet traffic ports 1
to 4
RJ-45 connector assembly for 10/100Base-T Ethernet traffic connection.
Port connection-status and activity LED indications are as for the NMS port.
15 Trib 1-4 and Trib 5
to 8
RJ-45 connector assemblies for wayside tributary connections; one RJ-45 port
per E1/DS1. E1 termination is set for unbalanced or balanced in 9500 MXC CT.
DS1 is 100 ohms balanced with options for AMI or B8ZS, and trib cable length.
Cable options provide extension to BNC connectors for unbalanced, or to RJ-45
plugs or unterminated wires for balanced.
No Item/Label Description
