Parameter Description
Web: Source IP Address Input
CLI: src-ip-addr-input
[SourceIPAddressInput]
Determines which IP address the device uses to determine
the source of incoming INVITE messages for IP-to-Tel
routing.
 [-1] = (Default) Auto Decision - if the IP-to-IP feature is
enabled, this parameter is automatically set to Layer 3
Source IP. If the IP-to-IP feature is disabled, this
parameter is automatically set to SIP Contact Header (1).
 [0] SIP Contact Header = The IP address in the Contact
header of the incoming INVITE message is used.
 [1] Layer 3 Source IP = The actual IP address (Layer 3)
from where the SIP packet was received is used.
Web: Use Source Number As Display
Name
EMS: Display Name
CLI: src-nb-as-disp-name
[UseSourceNumberAsDisplayName]
Determines the use of Tel Source Number and Display
Name for Tel-to-IP calls.
 [0] No = (Default) If a Tel Display Name is received, the
Tel Source Number is used as the IP Source Number
and the Tel Display Name is used as the IP Display
Name. If no Display Name is received from the Tel side,
the IP Display Name remains empty.
 [1] Yes = If a Tel Display Name is received, the Tel
Source Number is used as the IP Source Number and
the Tel Display Name is used as the IP Display Name. If
no Display Name is received from the Tel side, the Tel
Source Number is used as the IP Source Number and
also as the IP Display Name.
 [2] Overwrite = The Tel Source Number is used as the IP
Source Number and also as the IP Display Name (even if
the received Tel Display Name is not empty).
 [3] Original = Similar to option [2], except that the
operation is done before regular calling number
manipulation.
Web/EMS: Use Display Name as
Source Number
CLI: disp-name-as-src-nb
[UseDisplayNameAsSourceNumber]
Determines the use of Source Number and Display Name
for IP-to-Tel calls.
 [0] No = (Default) If IP Display Name is received, the IP
Source Number is used as the Tel Source Number and
the IP Display Name is used as the Tel Display Name. If
no Display Name is received from IP, the Tel Display
Name remains empty.
 [1] Yes = If an IP Display Name is received, it is used as
the Tel Source Number and also as the Tel Display
Name, and Presentation is set to Allowed (0). If no
Display Name is received from IP, the IP Source Number
is used as the Tel Source Number and Presentation is
set to Restricted (1).
For example: When 'From: 100
<sip:200@201.202.203.204>' is received, the outgoing
Source Number and Display Name are set to '100' and the
Presentation is set to Allowed (0).
When 'From: <sip:100@101.102.103.104>' is received, the
outgoing Source Number is set to '100' and the Presentation
is set to Restricted (1).
