At any given time during an active call, each of these parameters can be in one of the
following states according to its value in the last RTCP / RTCP XR packet:
Gray - indicates that the value is unknown
Green - indicates good call quality
Yellow - indicates medium call quality
Red - indicates poor call quality
The mapping between the values of the parameters and the color is according to the
configured threshold for these parameters, per Media Realm. The call itself also has a
state (color), which is the worst-state color of all the monitored parameters. Every time a
color of a parameter changes, a report is sent to the external server. In addition to this, a
report is sent at the end of each call.
Notes:
• The QoE feature is available only if the device is installed with the
relevant Software Upgrade Key.
• To configure the address of the AudioCodes Session Experience
Manager (SEM) server to where the device reports the QoE, see
'Configuring Server for Media Quality of Experience' on page 174.
• You can also use the QOERules ini file parameter to configure QoE per
Media Realm.
To configure Quality of Experience per Media Realm:
1. Open the Media Realm Table page (Configuration tab > VoIP menu > Media
submenu > Media Realm Configuration).
2. Select the Media Realm for which you want to configure Quality of Experience, and
then click the Quality Of Experience link; the Quality Of Experience page appears:
3. Click the Add button; the Add Record dialog box appears:
Figure 12-7: Add Record Dialog Box for QoE
The figure above shows value thresholds for the MOS parameter, which are assigned
using pre-configured values of the Low Sensitivity profile. In this example setting, if the
