Version 6.4 763 March 2012
SIP User's Manual A. Configuration Parameters Reference
Parameter Description
PhoneContext_Ton, PhoneContext_Context;
[\PhoneContext]
For example:
PhoneContext 0 = 0,0,unknown.com
PhoneContext 1 = 1,1,host.com
PhoneContext 2 = 9,1,na.e164.host.com
Notes:
This parameter can include up to 20 indices.
Several entries with the same NPI-TON or Phone-Context
are allowed. In this scenario, a Tel-to-IP call uses the first
match.
To configure the Phone Context table using the Web
interface, see 'Mapping NPI/TON to SIP Phone-Context' on
page 264.
For a description on using ini file table parameters, see
'Configuring ini File Table Parameters' on page 84.
Web/EMS: Add Phone Context As
Prefix
[AddPhoneContextAsPrefix]
Determines whether the received Phone-Context parameter is
added as a prefix to the outgoing ISDN Setup message with (for
digital interfaces) Called and Calling numbers.
[0] Disable = Disable (default).
[1] Enable = Enable.
A.12.18 LDAP Parameters
The Lightweight Directory Access Protocol (LDAP) parameters are described in the table
below. For more information on routing based on LDAP, refer to 'Routing Based on LDAP
Active Directory Queries' on page 175.
Table A-72: LDAP Parameters
Parameter Description
Web: LDAP Service
[LDAPServiceEnable]
Enables the LDAP feature.
[0] Disable (default)
[1] Enable
Note: For this parameter to take effect, a device reset is
required.
Web: LDAP Server IP
[LDAPServerIP]
Defines the LDAP server's IP address in dotted-decimal
notation (e.g., 192.10.1.255). The default is 0.0.0.0.
Web: LDAP Server Port
[LDAPServerPort]
Defines the LDAP server's port number.
The valid value range is 0 to 65535. The default port number
is 389.
Web: LDAP Server Domain Name
[LDAPServerDomainName]
Defines the host name of the LDAP server.
Web: LDAP Password
[LDAPPassword]
Defines the LDAP server's user password.
Web: LDAP Bind DN
[LDAPBindDN]
Defines the LDAP server's bind DN. This is used as the
username during connection and binding to the server.
