SIP User's Manual 738 Document #: LTRT-83310
Mediant 600 & Mediant 1000
Parameter Description
the call is sent to that channel.
b. If the number is not located or the channel is unavailable
(e.g., busy), the device searches, in ascending order, for
the next available channel in the Trunk Group. If located,
the call is sent to that channel.
c. If the device all the channels are unavailable, the call is
released.
Notes:
 For defining the channel select mode per Trunk Group, see
'Configuring Trunk Group Settings' on page 253.
 The logical (for digital interfaces) phone numbers of the device's
B-channels are defined by the TrunkGroup parameter.
Web: Default Destination
Number
[DefaultNumber]
Defines the default destination phone number, which is used if the
received message doesn't contain a called party number and no
phone number is configured in the Trunk Group Table' (see
Configuring the Trunk Group Table on page 251). This parameter
is used as a starting number for the list of channels comprising all
the device's Trunk Groups.
The default value is 1000.
Web: Source IP Address Input
[SourceIPAddressInput]
Determines which IP address the device uses to determine the
source of incoming INVITE messages for IP-to-Tel routing.
 [-1] = Auto Decision - if the IP-to-IP feature is enabled, this
parameter is automatically set to Layer 3 Source IP. If the IP-to-
IP feature is disabled, this parameter is automatically set to SIP
Contact Header (1). (default)
 [0] SIP Contact Header = The IP address in the Contact header
of the incoming INVITE message is used.
 [1] Layer 3 Source IP = The actual IP address (Layer 3) from
where the SIP packet was received is used.
Web: Use Source Number As
Display Name
EMS: Display Name
[UseSourceNumberAsDisplay
Name]
Determines the use of Tel Source Number and Display Name for
Tel-to-IP calls.
 [0] No = If a Tel Display Name is received, the Tel Source
Number is used as the IP Source Number and the Tel Display
Name is used as the IP Display Name. If no Display Name is
received from the Tel side, the IP Display Name remains empty
(default).
 [1] Yes = If a Tel Display Name is received, the Tel Source
Number is used as the IP Source Number and the Tel Display
Name is used as the IP Display Name. If no Display Name is
received from the Tel side, the Tel Source Number is used as
the IP Source Number and also as the IP Display Name.
 [2] Overwrite = The Tel Source Number is used as the IP
Source Number and also as the IP Display Name (even if the
received Tel Display Name is not empty).
 [3] Original = Similar to option [2], except that the operation is
done before regular calling number manipulation.
Web/EMS: Use Display Name
as Source Number
[UseDisplayNameAsSourceN
umber]
Determines the use of Source Number and Display Name for IP-to-
Tel calls.
 [0] No = If IP Display Name is received, the IP Source Number
is used as the Tel Source Number and the IP Display Name is
used as the Tel Display Name. If no Display Name is received
from IP, the Tel Display Name remains empty (default).

[1] Yes = If an IP Display Name is received, it is used as the Tel
