ST80 Masterview Operation and Setup 99
• The dead reckoned MOB page is displayed when valid dead-
reckoned data is available.
• The elapsed time is shown in minutes and seconds. This field is
filled with dashes if time data is not available .
• The range and bearing is from your boat to the person in the water.
Lat/Lon MOB Data
This display shows MOB data calculated using Lat/Lon. This
display only appears upon entry to MOB when dead-reckoned data
is not available.
D2689-1
Press this key momentarily
to display dead-reckoned
MOB data.
Press for 1 second to select
illumination adjustment.
masterview
MOB p POS
078o
TRUE
1.2 NM
08:30 ELAPSED
Waypoint 999
A waypoint with a “999” identifier is created if the man-overboard
key is activated. The following screen is displayed if the only MOB
data available is waypoint 999.
D2690-1
Press for 1 second to select
illumination adjustment.
masterview
MOB p POS
078o
TRUE
1.2
NM
