ST80 Masterview Operation and Setup 27
Depth Chapter
D2057-1
Water
Depth
Minimum
Depth
Fish
Finder
Depth
Offset
Depth
Histogram
PAGES
DEPTH
CHAPTER
Water Depth
The depth can be displayed in feet, fathoms or metres. However, the
currently displayed units are those selected in User Setup.
D2239-1
Go to the next chapter.
Press for 1 second to enter
illumination adjustment.
Go to next page or press for
1 second to return to the
previous page.
Display shallow, deep and
anchor alarms.
masterview
DEPTH
5.35
FT
If the rate at which the water depth changes is greater than the value
in User Setup, trend indicators ▲ (decreasing) or ▼ (increasing) are
displayed alongside the units.
What if the depth echo is lost?
• The last valid echo remains on screen until a new valid echo is
received.
• The words “LAST ECHO” are displayed.
