ST80 Masterview Operation and Setup
77
Old Heading
The old heading pop-up is displayed if you return to the previous
(old) heading.
•
A return to the previous (old) heading is achieved by pressing the
autopilot keypad
AUTO
key for 1 second.
D2085-1
OLD HDG
235 M
Old Wind Angle
This “pop-up” is displayed when the
STBY
and
AUTO
keys are
pressed for 1 second.
D2159-1
OLD WIND
45 S
•
The current wind angle is stored as the old autopilot wind datum.
79
81
