60 ST80 Masterview Operation and Setup
Selecting Lines
The default data line for the CDI is XTE. An alternative line can be
selected using the right-hand key (as shown previously) to cycle the
available sentences.
What if a Target Waypoint does not Exist?
The following “pop-up” is displayed if a target waypoint does not
exist.
D2149-1
NOT TRACKING
TO WAYPOINT
Position Page
SeaTalk Lat/Lon Data Available
This page displays your position and the current time, providing
position data is available on SeaTalk.
D2266-1
Go to the next chapter or
press for 1 second to enter
illumination adjustment.
Go to the next page or
press for 1 second to return
to the previous page.
masterview
050o49.49 N
001o02.98 W
Display log information.
POSITION
• The time field is replaced with dashes if time is not available.
• Time is displayed in the current system format.
