34 ST80 Masterview Operation and Setup
• Set the alarms using the or keys. The maximum wind speed
is 60 knots.
• The maximum wind angle is 180°.
• Once you have adjusted an alarm, press to return to the wind
alarm display.
Apparent Wind
Apparent wind displays the apparent wind speed and wind angle.
The wind direction is identified by a P for port or an S for starboard.
Alarms can be set for apparent wind to warn you when:
• the wind speed increases or decreases.
• the wind angle changes.
D2326-1
Go to the next chapter.
Press for 1 second to enter
illumination adjustment.
Go to the next page or press
for 1 second to return to the
previous page.
Display settings for apparent
wind alarms.
masterview
WIND APP
4.5
KTS
100
P
Alarm Control
This page displays the current settings the high and low speed and
high and low wind angle alarms.
Alarm Adjustment
Adjustment is identical to true wind.
To Next Page
