150 ST80 Masterview Operation and Setup
3.2 Masterview Display Heads
Entering Your Chosen Code Number at Power-On
(Manual High Security Mode)
If you have set CodeLock as described in the calibration chapter,
enter your chosen code number using the keys as shown.
D2685-1
Providing the code number
is correct, press this key to
accept the code and begin
normal operation.
Increase highlighted field
by 1
Decrease highlighted field
by 1
Highlight next code number
field.
masterview
▼
▼
▼
▼
ENTER CODE:
CODELOCK
Automatic CodeLock Transmission (Auto)
If you have selected auto, your CodeLock code number will be
automatically transmitted via SeaTalk to all compatible units.
3.3 Analogue Display Heads
Automatic CodeLock Systems
In an automatically transmitted CodeLock system the display head
reads the number sent on the SeaTalk bus and starts-up
automatically without any user input.
Manual CodeLock System
In a manually transmitted CodeLock system the code number
created on the master is entered via the keypad from any CodeLock
compatible instrument. This code is then sent to all compatible
instruments on the same SeaTalk bus. Once this code has been
received the instruments operate in the normal way.
