100 ST80 Masterview Operation and Setup
No Valid MOB Data
This screen is displayed if there is no valid data available during the
MOB condition.
D2691-1
Press for 1 second to select
illumination adjustment.
masterview
MAN
OVER
BOARD
Audible MOB Alarm
The audible MOB alarm consists of three 1 second beeps followed
by a 30 second break.
Keypad Handling
The Masterview can be used with the Navigator, Remote and
Autopilot keypads.
Navigator Keypad
The Navigator keypad must be linked to a Masterview to access the
extended features available using this keypad. Linking Navigator
keypad’s and Masterview display head’s is covered in the User
Setup chapter.
Remote Keypad
The remote keypad is used to mirror the Masterview key functions
from a remote location. In order to mirror the keypad functions,
Masterview display heads must be grouped to Remote Keypads.
The grouping procedure is covered in Remote keypad handbook.
Autopilot Keypad
When the Autopilot keypad is used with a Masterview with the
autopilot chapters selected, the Masterview can be used as an
autopilot control unit. Linking of the autopilot keypad and a
Masterview is automatic.
