108 ST80 Masterview Operation and Setup
3. Press and then sail or motor from “point 1” to “point 2”.
1
2
D2205-1
DISTANCE = 1NM (APPROX)
4. When you arrive at point 2 press . Providing the logged distance is
within the acceptable range, the following “pop-up” is displayed.
D2204-1
Note: A run may be cancelled by pressing the key — the message
“INVALID RUN, CHECK TRANSDUCER” is displayed. You must
then press to advance to the “return run” display (action 6).
5. Press to accept the first run — “RETURN RUN?” is now
displayed.
Note: If you want to cancel the calibration procedure at this stage, press
to return to the “calibration factor” page.
