Copy Set
• Delete Set
The Insert Row option adds a point above the current point.
The F3/
Ok
Function Key saves the custom test point set and adds it
to the
Define Steps
combo list. It is located after all pre-entered test
point sets, before the
Create New
option.
To separate custom point sets from pre entered ones, custom point
sets are prefixed "User:" and the row ends with a chevron pointing
right " ". This indicates that the point set may be edited.
Hints!
The point values need not be in ascending order or even inside the
range limits.
To force MC4 to stay in one point for a longer time, enter the same
point value to several successive points.
Notes.
The step values are saved as floating point number percentage
values so the steps may be used for any Function and range. The
percentage values are proportioned to the current Stepping /
Manual Stepping range.
The percentage values shown to the right of the test points are
whole number near values of the entered values. They are for
information only.
The available free memory defines how many custom test points
may be saved. If there is not enough memory left to save a custom
test point set, MC4 displays an error message suggesting that you
first free some memory and then retry adding a custom test point
set.
