MC4 User Guide 145
Calibration Window Menu
This section presents the menus available in the calibration window.
Menu When Calibration is NOT Started
The following menu options are available when the calibration win-
dow is open, but a calibration is not started, i.e. the F3/
Start
Func-
tion Key is still visible.
MENU ITEM DESCRIPTION
Close
Allows you to close the calibration window
and return to the Plant Structure window.
Calibration Infor-
mation
Displays calibration related information on
two pages.
The displayed information consists of error
calculation data, input and output Function
and range data and instrument identifica-
tion data (Position ID an Function Name).
Switch between pages using the F2/
More
Function Key.
Adjust Instrument
Opens the calibration window with added
functionality helping you adjust the instru-
ment.
Note that Function Key allows you to
jump between instrument input range's
minimum and maximum. This feature is
useful when the instrument's input signal is
generated/simulated with MC4.
Continues on next page+
