About Instrument Calibration
MC4 User Guide 133
Examples of Instrument
Calibration
The following pages contain a few examples of how to calibrate an
instrument using MC4.
When uncertain, consult Part B of this manual for information on how
to connect instruments and configure the windows of MC4 to suit the
instrument's needs.
The following calibration examples are presented in this manual:
• Pressure Transmitters on page 134,
• Temperature Indicators and Recorders on page 136,
• Temperature Sensors on page 138,
• Pneumatic Pressure Transmitters and Converters on page
140 and
• Electrical Limit Switches on page 142.
Warning!
Working with pressure instruments can be hazardous. Only
qualified personnel may use pressure instruments and pres-
sure sources. See pressure measurement related warnings in
Part A of this manual.
