Additional Calibration Related Information
178 MC4 User Guide
Accepting Calibration Points Automatically
The following rules apply when MC4 automatically accepts calibra-
tion points:
• The input must be inside the Max Point Deviation target ar-
ea before the automatic calibration point acceptance proce-
dure initiates.
• If Require also Stable Output Measurement check box is
set, the following procedure applies:
1. As long as the input and/or output is unstable (symbol
visible in Numeric Mode), calibration points are not
automatically accepted.
2. When both input and output are stable, MC4 waits for a
time period defined in Setpoint Delay field.
3. During the wait time:
If either input or output is unstable, the wait time is in-
terrupted and MC4 restarts the procedure from the be-
ginning.
4. In case both input and output were stable all through
the wait time, the results are automatically saved.
• Otherwise, the following procedure applies:
1. As long as the input is unstable, calibration points are
not automatically accepted.
2. When input is stable, MC4 waits for a time period de-
fined in Setpoint Delay field.
3. During the wait time:
If input is unstable, the wait time is interrupted and MC4
restarts the procedure from the beginning.
4. In case input was stable all through the wait time:
If output is stable, the results are automatically saved.
If output is unstable, MC4 waits for an additional five
seconds allowing the output to settle. Then the results
are saved no matter how unstable the output may be.
If you accept a calibration point using F3/ Accept Function Key, the
following rules apply (no matter if you are using Automatic
Calibration Point Acceptance or not):
• If the input is unstable, a window opens asking you to confirm
the accepting of the calibration point although the input is un-
stable.
• If Require also Stable Output Measurement is set and
the output is unstable, MC4 asks you to confirm the accepting
of the calibration point.
• Otherwise, MC4 accepts the calibration point.
