Tools Menu
90 MC4 User Guide
Showing Data on the Additional Info Row
As presented in section A's User Interface chapter, both Basic Mode
windows have an Additional Info row for showing additional data.
Each window may have two values shown on their respective
Additional Info rows. The only exception is the bar graph option. It
reserves the whole Additional Info row alone.
All Additional Info Row settings are in: F1/
Setup
or F2/
Setup
(depending on which window you want to change the display mode
for), F2/
Tools
. Select
Show Additional Info
from the opened
menu.
The data available to be shown on the Additional Info row can be
divided into following groups:
Data that is Always Available.
Can be selected to be shown at any time.
Display Mode and Special Measurement Related Data.
Data that is available to be shown depending on Display Mode
and Special Measurement settings.
Function Dependent Data.
Data that is available for certain Functions, e.g. barometric
pressure when it is needed.
The following chapters present the data available to be shown on the
Additional Info row. Any limitations as to when the data is available
are mentioned where applicable. Below each heading is the icon or
unit displayed on the Additional Info row when that particular
Additional info is shown.
Maximum value
Displays the found maximum value after a measurement was started
or it was reset.
Minimum value
Displays the found minimum value after a measurement was started
or it was reset.
Rate of Change Value (unit 1/min)
Displays the calculated rate of change value (units/min) found after a
measurement was started or the calculation was reset.
