MC4 User Guide 177
Additional Calibration
Related Information
This chapter and its subchapters complement information presented
in other section D chapters.
Extra Information Saved With Calibration Point Data
Along with the input and output values, MC4 saves the following da-
ta for each calibration point (when applicable). Some data is stored
automatically and some may be manually entered.
Data automatically stored by MC4:
• MC4 modules used in current calibration point and
• Resolution for manually entered value.
Data that can be manually entered on point level:
• Used Reference Module for manually entered value,
• Separate Barometric Module used in conjunction with high
pressure gauge modules,
• Reference Sensor for manually entered value, and measured
values and
• Sensor used for measuring the temperature of the Reference
Junction for manually entered value, and when an external
sensor is used for measuring the Reference Junction.
Note that this data may be edited in the calibration window's menu
(F1/
Menu
,
Instrument Input
and F1/
Menu
,
Instrument Output
). Which ones are available depends on the selected Input/Output
Function.
Furthermore, when applicable, corresponding data is shown among
calibration results.
