Editing Instrument Data
MC4 User Guide 157
Position Data Page
Position related data.
FIELD DESCRIPTION
Position ID
Position ID is the field, that identifies an
instrument position (tag),
e.g. PT101.5
Position Name
A text field for giving a descriptive name to
the position,
e.g. "Pressure Transmitter #5 at reactor
#101".
Position Location
A text field for describing the location of the
position, e.g. "This position located on top
of reactor 101. Level 10.2"
What identifies the instrument in MC4's instrument list.
MC4's instrument list displays one of the following fields/text in the
instrument list. The list is hierarchical, i.e. the uppermost is shown if
it is not empty. The last text is shown if all of the previously men-
tioned fields are empty:
1. Position ID (found among position data)
2. Position Name (found among position data)
3. Device ID (found among device data)
4. Serial number (found among device data)
5. (no name)
