Editing Instrument Data
MC4 User Guide 161
Output Data Page
Data related to the instrument's output.
Note that this list presents all output data page fields. The ones visi-
ble for you depends on the selected
Function
(first field in the list
below):
FIELD DESCRIPTION
Function
The Function needed in MC4 to determine
the instrument's output.
Display Resolution
Select a suitable display resolution from
the available list.
This field is visible when the selected
Function is:
Manually Keyed Value
Unit
This field is visible for all Functions
Sensor
Select an applicable sensor from the avail-
able list.
This field is visible when the selected
Function is:
T/C Sensor Measurement
or
RTD Sensor Measurement
RJ Mode
Select an applicable Reference Junction
Mode from the available list. More info of
Reference Junction Modes in part C, chap-
ter Internal Reference Junction on page
113 and External Reference Junction on
page 114.
This field is visible when the selected
Function is:
T/C Sensor Measurement
.
HART Compatible
Loop Supply
Check if the current supplied by MC4
needs to be HART Compatible.
This field is visible when the selected
Function is:
Current Meas., Supply On
.
Continues on next page+
