Maintaining MC4's Instrument Database
162 MC4 User Guide
FIELD (cont.) DESCRIPTION
Switch Sound
Defines when MC4 emits a sound when
the switch changes its state. Options:
No Sound
Sound Open
Sound Closed
When Changed
This field is visible when the selected
Function is:
Switch .
Trigger Edge
Select whether it is the Rising or the Falling
edge that Pulse Counting uses.
This field is visible when the selected
Function is:
Pulse Counting .
Trigger Level
Specify the trigger level and whether to use
a test voltage during the measurement.
This field is visible when the selected
Function is:
Frequency Measurement ,
Pulse Counting or
Switch .
Invert Switch
Open/Closed States
Check if you want to display the switch's
state inverted in MC4.
This field is visible when the selected
Function is:
Switch .
