Instrument List Window Menu
Many of the instrument list window's menu items have dual function-
ality. Which functionality is active depends on what is highlighted in
the instrument list window.
The two important options in this menu are the Create New option
and Management option. The first one allows you to add new in-
struments and plant structure branches. The latter includes a sub-
menu for deleting instruments, plant structure branches and cal-
ibration results.
MENU ITEM DESCRIPTION
Select
If a plant structure level is highlighted,
the level is selected for viewing.
If an instrument is highlighted, the calibra-
tion window opens and you may calibrate
the selected instrument
Note that you do not necessarily need to
use this menu option. Pressing Enter ( )
in the instrument list window does the
same thing.
Details
If a plant structure level is highlighted,
the location of the level is shown by dis-
playing a list (path) of all higher levels. You
may also add a note for the selected plant
structure level.
If an instrument is highlighted, some basic
instrument data is shown. Among the data
there is the selected MC4 Function for the
instrument's input and output.
By pressing F2/ More , another page opens
displaying the instrument's location, just as
was shown for plant structure levels.
Result History
Visible only when saved calibration data
exists for the selected instrument in MC4's
memory. More of viewing results in chapter
Viewing Calibration Results on page
174.
Continues on next page+
