Parallel Functions in MC4
MC4 User Guide 121
Parallel Functions in MC4
This chapter explains what kind of simultaneous duties MC4 can do.
All of the following tasks may run independently, but the window
settings decide what is shown:
Each internal or external pressure measurement runs
independently.
One electrical measurement in the
Measure
terminals.
One electrical measurement and one electrical generation/simu-
lation in the
Temperature / Generate
terminals.
Additionally, all of the connectors on the left side of MC4 may have
an independent task.
Notes.
The Barometric module can always be used for pressure type
conversion, even if it is already active in any window.
See Part D, Calibration, chapter Supported Input/Output Signal
Combinations for additional info on which Functions may
simultaneously be active during instrument calibration .
