Menu When a Calibration is Running
MC4 User Guide 147
Menu When a Calibration is Running
The following menu options are available when the calibration win-
dow is open and a calibration is running.
Note that the calibration is paused as long as this menu is open.
Once the menu is closed, the calibration continues, unless the
Pause option was selected..
MENU ITEM DESCRIPTION
Reject/Cancel Cali-
bration
Allows you to close the calibration window
and return to the Plant Structure window
without saving any calibration results.
Save Incomplete
Calibration
Allows you to save the results of a partly
done calibration. When selected, the result
window opens. Use the F3/ Save Function
Key to save the results.
After saving you return to the calibration
window and may either start a new calibra-
tion run or close the calibration window.
Calibration Infor-
mation
Displays calibration related information on
two pages.
The displayed information consists of error
calculation data, input and output Function
and range data and instrument identifica-
tion data (Position ID an Function Name).
Switch between pages using the F2/ More
Function Key.
Pause
Keeps the calibration paused although the
menu is closed. When selected, you may
continue using F3/ Continue Function Key.
Undo Point
Allows you to undo previous calibration
point. Available only when there are previ-
ously accepted calibration points.
Skip Point
Allows you to skip current calibration point.
Advances to the next point (if applicable)
without saving the results of current point.
Continues on next page+
