Editing Instrument Data
MC4 User Guide 163
Function Data Page
Data related to the instrument's functionality.
FIELD DESCRIPTION
Input Range, 0 %
100 %
Enter the input range's minimum and max-
imum value here.
Transfer Function
Defines the instrument's input/output corre-
lation.
Available options (with no custom Transfer
Functions):
Linear
√x
√x3
√x5
√x2
Create New…
The last item in the list allows you to make
your own custom transfer function. Custom
transfer functions are presented in chapter
Custom Transfer Functions on page 103.
This field is visible for all other instruments,
except Switch es.
Output Range, 0 %
100 %
Enter the output range's minimum and
maximum value here.
This field is visible for all other instruments,
except Switch es.
Set Action
Here you define what a switch does when
it sets (actuates). Available options:
Opens
Closes
This field is visible when the selected
Function is:
Switch .
Nominal Set & Re-
set
Enter the switch's nominal set and reset
(actuating and deactuating) point values
here.
This field is visible when the selected
Function is:
Switch .
Continues on next page+
