BEAMEX MC4 - External Pressure Modules (EXT), High Accuracy

Appendix 1, Technical Data
200 MC4 User Guide
External Pressure Modules (EXT), High Accuracy
Module Unit Range
3)
Resolution Accuracy
1)
(±) 1 Year Uncertainty
2)
(±)
EXT B
kPa a
mbar a
psi a
80 to 120
800 to 1200
11.6 to 17.4
0.01
0.1
0.001
0.3 mbar
0.05 kPa
0.5 mbar
0.0073 psi
EXT10mD
kPa diff
mbar diff
iwc diff
± 1
± 10 mbar diff
± 4
0.001
0.05 % Span 0.05 % Span + 0.1 % RDG
EXT100m
kPa
mbar
iwc
0 to 10
0 to 100
0 to 40
0.0001
0.001
0.001
0.015 % FS + 0.0125 % RDG 0.025 % FS + 0.025% RDG
EXT400mC
kPa
mbar
iwc
± 40
± 400
± 160
0.001
0.01
0.001
0.01 % FS + 0.0125 % RDG 0.02 % FS + 0.025% RDG
EXT1C
kPa
bar
psi
± 100
± 1
-14.5 to 15
0.001
0.00001
0.0001
0.007 % FS + 0.0125 % RDG 0.015 % FS + 0.025% RDG
EXT2C
kPa
bar
psi
-100 to 200
-1 to 2
-14.5 to 30
0.001
0.00001
0.0001
0.005 % FS + 0.01 % RDG 0.01 % FS + 0.025% RDG
EXT6C
kPa
bar
psi
-100 to 600
-1 to 6
-14.5 to 90
0.01
0.0001
0.001
0.005 % FS + 0.01 % RDG 0.01 % FS + 0.025% RDG
EXT20C
kPa
bar
psi
-100 to 2000
-1 to 20
-14.5 to 300
0.01
0.0001
0.001
0.005 % FS + 0.01 % RDG 0.01 % FS + 0.025% RDG
EXT60
kPa
bar
psi
0 to 6000
0 to 60
0 to 900
0.1
0.001
0.01
0.005 % FS + 0.0125 % RDG 0.01 % FS + 0.025% RDG
EXT100
MPa
bar
psi
0 to 10
0 to 100
0 to 1500
0.0001
0.001
0.01
0.005 % FS + 0.0125 % RDG 0.01 % FS + 0.025% RDG
EXT160
MPa
bar
psi
0 to 16
0 to 160
0 to 2400
0.0001
0.001
0.01
0.005 % FS + 0.0125 % RDG 0.01 % FS + 0.025% RDG
EXT250
MPa
bar
psi
0 to 25
0 to 250
0 to 3700
0.001
0.01
0.1
0.007 % FS + 0.0125 % RDG 0.015 % FS + 0.025% RDG
EXT600
MPa
bar
psi
0 to 60
0 to 600
0 to 9000
0.001
0.01
0.1
0.007 % FS + 0.01 % RDG 0.015 % FS + 0.025% RDG
EXT1000
MPa
bar
psi
0 to 100
0 to 1000
0 to 15000
0.001
0.01
0.1
0.007 % FS + 0.01 % RDG 0.015 % FS + 0.025% RDG
Term ’FS’:
'FS' is the Full Scale of the positive side range. E.g. for ±200 mbar module, the Full Scale is 200 mbar.
1)
Accuracy includes hysteresis, nonlinearity, repeatability and reference standard uncertainty (k=2).
2)
1 Year Uncertainty includes hysteresis, nonlinearity, repeatability and typical long term stability for mentioned
period (k=2).
3)
Every internal/external pressure module’s range may be displayed also in absolute pressure if the Barometric
Module (B) is installed.
