BEAMEX MC4 - Scaling

Tools Menu
86 MC4 User Guide
Scaling
In Scaling a measured/generated/simulated value may be converted
to whatever "quantity" is needed, provided the conversion
information is known.
When measuring, the measured value is replaced by the scaled
value. The actual measurement value in engineering units is shown
on the additional info row as seen in the rightmost picture.
When generating/simulating, the scaled value is the editable one
and the generated/simulated value in engineering units is shown on
the additional info row.
S C A L I N G
T r a n s f e r F u n c t i o n
S t o p C a p t u r e O k
 m A
G a u g e I N T
1 0 . 8 6
I n p u t R a n g e ( 0 % . . . 1 0 0 % )
S c a l e d R a n g e ( 0 % . . . 1 0 0 % )
L i n e a r
4 . 0 0 0 2 0 . 0 0 0
S e t u p

S e t u p

M e n u
 N o n e
2 1 . 0 9 . 2 0 0 4 1 1 : 1 6 : 2 2
 G a l l o n s / m i n
S c a l e d
1 2 3 . 6 7
1 0 . 8 6
A
When Scaling display is active, the entered unit (or the text " scaled
unit " if the unit was not entered) is displayed after the warning
triangle and the text " Scaled " is shown above the Scaled value.
To configure Scaling, enter Input Range values for the selected
quantity, set the Transfer Function , enter the Scaled Range and
the Unit of the scaled range. The display resolution may also be
edited, if needed.
Notes.
If anything else was selected for display on the additional info row,
the main measurement of the window replaces the previous
additional info data.
Also: if you select two other items to be displayed on the additional
info row while Scaling display is active, the second item replaces the
windows' main measurement data. Beware of the problems that
may result in not seeing the true measurement value.
For help on making Custom Transfer Functions, see Part C,
chapter Custom Transfer Functions on page 103.
