BEAMEX MC4 - Input Data Page

Editing Instrument Data
MC4 User Guide 159
Input Data Page
Data related to the instrument's input.
Note that this list presents all input data page fields. The ones visible
for you depends on the selected Function (first field in the list be-
low):
FIELD DESCRIPTION
Function
The function needed in MC4 to determine
the instrument's input.
Display Resolution
Select a suitable display resolution from
the available list.
This field is visible when the selected
Function is:
Manually Keyed Value
Unit
This field is visible for all Functions
Sensor
Select an applicable sensor from the avail-
able list.
This field is visible when the selected
Function is:
T/C Sensor Measurement ,
T/C Sensor Simulation ,
RTD Sensor Measurement or
RTD Sensor Simulation .
RJ Mode
Select an applicable Reference Junction
Mode from the available list. More info of
Reference Junction Modes in part C, chap-
ter Internal Reference Junction on page
113 and External Reference Junction on
page 114.
This field is visible when the selected
Function is:
T/C Sensor Measurement or
T/C Sensor Simulation .
HART Compatible
Loop Supply
Check if the current supplied by MC4
needs to be HART Compatible.
This field is visible when the selected
Function is:
Current Meas., Supply On .
Continues on next page+
