Display Mode and Special Measurements
MC4 User Guide 81
Display Mode and Special Measurements
The Display Mode and Special Measurements utility is always
available, but the available options vary depending on the selected
Function.
All Display Mode settings are in: F1/
Setup
or F2/
Setup
(depending on which window you want to change the display mode
for), F2/
Tools
. Select
Display Mode / Specials
from the opened
menu.
When a Display Mode or a Special Measurement is active, the
measurement window display a warning ( ) to indicate that the
reading is not the actual measured value. Depending on the selected
Display Mode or Special Measurement, some additional text is also
shown.
All Display Mode and Special Measurement settings revert to
Normal display mode if you select another quantity. Additionally, the
same menu were a Display Mode or a Special Measurement was
invoked also includes a possibility to revert back to
Normal Display
Mode
.
Note applying to all display modes and special measurements.
While performing display mode and/or special measurement
calculations, MC4 uses numbers that have more decimals than are
available on the display. In some cases these extra digits may cause
rounding that differs from values that are shown on display. Notable
differences between shown and manually calculated values usually
mean that MC4's accuracy is not suitable for the given task.
