Editing Instrument Data
MC4 User Guide 165
Procedure Data Page
MC4 Data related to the calibration procedure.
Since the fields for switches and non-switches (i.e. regular instru-
ments) vary significantly, they are presented in separate tables.
Procedure fields for non-switches
(Procedure fields for switches are presented further on )
FIELD DESCRIPTION
Calibration Points
Defines how the stepping is done
Available options (with no custom sets):
3: 50 %
5: 25 %
6: 20%
11: 10 %
0%>10>25>50>75>90>100
0%>2>4>50>96>98>100
0%>5>40>100
-2%>0>2>4>50>96>98>100>102
Create New…
The group of sets starting with a number
and colon are sets with fixed step sizes.
The first number is the amount of step lev-
els and the percentage value is the step
size.
The group of sets starting with a number
and percentage symbol are sets with vary-
ing step sizes (suitable for, e.g. valve
tests). Each number is a step level.
The last item in the list allows you to make
your own custom step definition. Custom
steps are presented in chapter Custom
Test Point Sets on page 101.
Repeat Format
This setting specifies how the calibration
points are used during calibration. Availa-
ble options:
Up / Down
Down / Up
Up
Down
Continues on next page+
