Maintaining MC4's Instrument Database
170 MC4 User Guide
Error Limits Data Page
Data related to the error calculation and error limits.
FIELD DESCRIPTION
Error Calculation
Method
Select one of the error calculation methods
Available options:
% of output span
Absolute (input unit)
Absolute (output unit)
More in depth presentations of the options
are available in chapter Error Calculation
Formulas on page 181.
Reject if >
Calibration fails if found error exceeds this
value at some point.
Adjust if >
If value is other than zero, MC4 suggests
that you do adjust the instrument if found
error exceeds this value at some point.
Do not adjust if <
If value is other than zero, MC4 suggests
that you do not adjust the instrument if
found error exceeds this value at some
point.
Adjust to <
If value is other than zero, MC4 suggests
that you adjust the instrument's found max-
imum error below this limit.
Display Resolution
Active only if is
Error Calculation Meth-
od
set to "% of span". Then you may select
one of the available resolutions for present-
ing the calculated error.
Error Calculation
Domains
Set Point
Reset Point
Defines which types of error are taken into
account with switches. Both Set and Reset
point have their own independent settings.
Available options:
+/-,
All errors are reported/valid
+,
Only positive errors are valid
-,
Only negative errors are valid
None
No errors are reported
This field is visible for switches only
Continues on next page+
