BEAMEX MC4 - External Pressure Modules (EXT), Standard Accuracy

Appendix 1, Technical Data
202 MC4 User Guide
External Pressure Modules (EXT), Standard Accuracy
Module Unit Range
(2
Resolution 1 Year Uncertainty
(1
EXT200mC-s kPa
mbar
iwc
±20
±200
±80
0.001
0.01
0.01
0.05% RDG + 0.05% FS
EXT2C-s kPa
bar
psi
-100 ... 200
-1 ... 2
-14.5 ... 30
0.01
0.0001
0.001
0.05% FS
EXT20C-s kPa
bar
psi
-100 ... 2000
-1 ... 20
-14.5 ... 300
0.1
0.001
0.01
0.05% FS
EXT160-s MPa
bar
psi
0 ... 16
0 ... 160
0 ... 2400
0.001
0.01
0.1
0.05% FS
Term ’FS’:
'FS' is the Full Scale of the positive side range. E.g. for ±200 mbar module, the Full Scale is 200 mbar.
Feature Specification
Temperature coefficient <±0.001 % Rdg/°C outside 1535°C (59  95 °F)
Maximum overpressure 2 × Range
Pressure port EXT160-s:
G 1/8” female (parallel )
All others:
G1/8” (ISO228/1) female. A conical 1/8” BSP male with
60° internal cone adapter included for Beamex hose set.
Wetted parts AISI316 stainless steel, Hastelloy, Nitrile rubber.
Pressure media EXT200mC-s and EXT2C-s:
Dry clean air or other clean, inert, non-toxic,
non-corrosive gases
EXT20C-s and EXT160-s:
Clean, inert, non-toxic, non-corrosive gases or liquids
Use of pressure media classified as dangerous is prohibited.
Dimensions,
length / width / depth
145 mm / 45 mm / 55 mm
(5.7" / 1.8" / 2.2")
Weight 0.5 kg (1.1 lb)
Operating temperature -10+50°C (14122 °F)
Storage temperature -20+60°C (-4140 °F)
Humidity range 080 % R.H. non-condensing
1)
Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long term
stability for mentioned period (k=2).
2)
Every internal/external pressure module’s range may be displayed also in absolute pressure if the Barometric
Module (B) is installed.
All standard accuracy external pressure modules are also compatible with Beamex MC5 and MC5P Calibrators
(firmware version 1.90 and onwards).
All specifications are subject to change without prior notice
