112 MC4 User Guide
Square Rooting
Pressure transmitters or converters used for flow measurement often
have square rooting character. Here are a couple of examples on
how you can configure MC4 to take into account the instrument's
square rooting character:
1. Set the Display Mode of window that measures the
instrument's output signal to
Error Percentage
and make sure
the
Transfer Function
field is set to Square Rooting (√x).
2. Use Scaling to convert the instrument's output signal to a
suitable format and again, make sure the
Transfer Function
field is set to Square Rooting (√x).
Display Modes as well as scaling is discussed in chapter Tools
Menu in part B of this User Guide.
