Tools Menu
80 MC4 User Guide
FIELD
(cont.)
DESCRIPTION/OPTIONS
Transfer Function
Defines the input/output correlation.
Available options:
Linear
√x
√x3
√x5
x2
Create New…
The last item in the list allows you to
make your own custom Transfer
Function. See Custom Transfer
Functions on page 103.
*
)
Warning!
Do not configure the range settings so that they exceed the al-
lowed input range of the connected instrument. MC4
determines the limits of the range settings based on the
selected quantity and port, not the connected instrument.
See also:
Spinning and Manual Stepping on page 54.
