Switch State Sensing
MC4 User Guide 49
Use Switch Sound field to assign an "alarm" to a switch. Then you
can use switch test for conductivity/continuity tests with no need to
look at the display.
You can invert the switch's open/closed state indication using the
check box available in the measurement window's setup window.
This can be used to show real switch state when switch state
sensing is connected to relay coil instead of relay contacts.
Next
Tools Menu on page 67
Alarms on page 69
Calibration, see Part D.
